Chint universal circuit breaker NA1-2000X-1250A

The Chint universal circuit breaker NA1-2000X-1250A is an electrical device suitable for power distribution networks with an alternating current (AC) frequency of 50Hz, a rated working voltage up to AC690V, and a rated working current up to 6300A and below. The following detailed introduction will be presented from dimensions such as its functional characteristics, application scenarios, and technical parameters:

 Functional Characteristics

- **Comprehensive Protection Functions*CHNT NL1E - 63A circuit breaker

  It provides multiple fault protections for circuits and power equipment, including overload, undervoltage, short circuit, and single-phase grounding. When an overload occurs in the circuit, the thermal element of the thermal release generates heat, causing the bimetallic strip to bend, which pushes the free release mechanism to act and disconnect the main circuit. In case of a short circuit or severe overload, the armature of the overcurrent release is attracted, also causing the free release mechanism to act and cut off the circuit.

- **Intelligent Control*Chint NXBLE-40C6 residual current circuit breaker (RCCB)*

  Equipped with intelligent protection functions, it offers precise selective protection. It can real-time monitor parameters such as current, voltage, and power, and perform intelligent control and protection according to set rules, improving power supply reliability and avoiding unnecessary power outages.

- **Diverse Operation Modes*Chint NXR series thermal overload relays price*

  The operating mechanism can be installed on the front or right side, supporting both manual operation and electric closing, facilitating users to operate in different scenarios. Meanwhile, it is equipped with "trip" and "close" indicators as well as a manual disconnection button, enabling operators to intuitively understand the working status of the circuit breaker.

- **Abundant Accessory Expansion*CHINT circuit breaker price*

  With complete accessory expansion functions, it can meet the needs of extended functions in different application scenarios. For example, adding auxiliary contacts, alarm contacts, shunt trip devices, undervoltage trip devices, etc., to achieve more control and monitoring functions for the circuit.

 Application Scenarios

- **Industrial Field*CHINT surge protector price*

  Suitable for power distribution systems in various factories, mines, and other places, it can be used to protect important equipment such as motors, transformers, and generators, ensuring the stable operation of industrial production.

- **Commercial Buildings**

  Widely applied in modern high-rise buildings and intelligent buildings, it provides reliable power distribution protection for equipment such as lighting, air conditioning, and elevators in commercial places.

- **Power Energy**

  In green energy projects such as wind power and solar power, it can be used for power distribution and line protection, ensuring the stable transmission and utilization of energy.

 Technical Parameters

- **Rated Working Current**: The rated working current of this circuit breaker is 1250A, capable of meeting the power supply needs of a certain scale of electrical equipment.

- **Rated Ultimate Short-Circuit Breaking Capacity**: The rated ultimate short-circuit breaking capacity of the NA1 series universal circuit breakers ranges from 42-120kA. For the specific model NA1-2000X-1250A, its short-circuit breaking capacity can be determined according to actual needs and product specifications.

- **Installation Methods**: It supports two installation types, draw-out type and fixed type, allowing users to choose according to actual installation space and usage requirements.

 Product Advantages

- **Safe and Reliable**

  It fully covers extremely high to extremely low temperature environments, ensuring the reliable operation of the power distribution system in harsh environments. Additionally, it has a long service life, which can reduce the later maintenance and replacement costs for clients.

- **Flexible and Easy to Use**

  It not only has multiple installation methods and operation modes but also its intelligent control unit can solve the difficulties of data collection and remote operation for controlling circuit breaker closing and tripping.

**Partial technical parameters of the Chint universal circuit breaker NA1-2000X-1250A are as follows**:

- **Rated Current**: 1250A (frame current 2000A)

- **Rated Voltage**: AC rated working voltage up to AC690V, rated insulation voltage is generally 1000V (there may be slight differences in different documents, and the parameter range of the NA1 series is usually similar). The 3C rated voltage range is AC rated voltage 1500V (there is a relevant description, but in practical applications, conventional parameters such as working voltage below 690V are mainly concerned).

- **Breaking Capacity**: Multiple options for breaking capacity, such as 36kA/50kA/75kA, etc. (specifically depending on product configuration and selection, different breaking capacities correspond to different application scenarios and short-circuit current levels).

- **Rated Short-Time Withstand Current**: 50kA (1s).

- **Number of Poles**: 4P (common configuration, other pole numbers are also available, but this model is commonly 4 poles).

- **Operation Mode**: Including manual operation and electric closing, etc., with an operation frequency generally of 10,000 times (the limit of operation times under normal use conditions).

- **Installation Method**: Can adopt draw-out type installation (other installation methods such as fixed type are also available, and the draw-out type is convenient for maintenance and repair).

- **Arcing Distance**: Generally 14mm (there may be differences under different specifications and conditions, this is a common reference value).

- **Control Circuit Voltage**: The highest working voltage of the control circuit is AC400V, and the installation category of the auxiliary circuit is III (involving the working voltage range and installation requirements of the control circuit and auxiliary circuit, etc.).

- **Auxiliary Contact Capacity**: The capacity of auxiliary contacts is generally AC230V, 5A (different types of auxiliary contacts may have different capacities, this is a common value).
