Siemens 6SL3210-1PB13-8AL0 is a power module

      The Siemens 6SL3210-1PB13-8AL0 is a power module of the SINAMICS G120 series, specially designed for industrial drive systems. It is suitable for **200-240V single-phase/three-phase AC input** (voltage fluctuation ±10%) and supports scenarios with **0.55kW heavy overload** (200% load for 3 seconds) and **0.75kW light overload** (150% load for 3 seconds). The following is a detailed collation of parameters:

I. Core Electrical Parameters

1. **Input Specifications*Siemens model number 6SL3210-1KE23-2UF1*

   - **Voltage Range**: 200-240V AC (1-phase/3-phase), 47-63Hz. Equipped with a Class A filter and braking chopper, it can be directly connected to a TN power supply system to reduce electromagnetic interference.

   - **Input Current**: Maximum 3.2A in heavy overload (HO) mode and 4.1A in light overload (LO) mode, suitable for mainstream small and medium-power motors.

2. **Output Capability*Siemens S7-1200 series PLC*

   - **Power Rating*Siemens 6ES7253-1AA22-0XA0 (EM253)*:

     - Heavy Overload (HO): 0.55kW (200% load for 3 seconds, 150% load for 57 seconds within a 300-second cycle).

     - Light Overload (LO): 0.75kW (150% load for 3 seconds, 110% load for 57 seconds within a 300-second cycle).

   - **Output Frequency**: 0-650Hz, supporting multiple control modes such as V/f control and vector control.

3. **Interrupting Capacity*Siemens 6ES7235-0KD22-0XA0*

   - Built-in short-circuit protection safely cuts off fault currents, complying with the IEC 61800-5-1 standard. Although the specific breaking current value is not explicitly stated in public information, the module is designed to support highly reliable short-circuit protection.

II. Physical and Environmental Parameters

1. **Mechanical Characteristics*Siemens 6ES7231-5QA30-0XB0 module*

   - **Dimensions**: 196mm (height) × 73mm (width) × 165mm (depth), with an IP20 protection rating, requiring installation in a control cabinet.

   - **Weight**: Approximately 1.5-1.72kg (slightly varying with configurations).

   - **Installation Method**: Only vertical installation is supported, with the integrated operation panel facing upward to ensure heat dissipation efficiency.

2. **Environmental Adaptability*6ES7142-5AF00-0BA0 Siemens*

   - **Operating Temperature*Siemens 1FL6034-2AF21-1LH1 Servo Motor*:

     - Heavy Overload (HO): -10°C to +50°C (no derating), derating required above 50°C.

     - Light Overload (LO): -10°C to +40°C (no derating), derating required above 40°C.

   - **Storage Temperature**: -40°C to +70°C, relative humidity <95% (non-condensing).

   - **Altitude**: Up to 1000 meters (no derating), requiring output power adjustment based on altitude beyond this.

3. **Cooling Method*Siemens converter 6SE6440-2UD42-0GA1*

   - Adopts **forced air cooling** design, improving heat dissipation efficiency through a built-in fan, suitable for installation in control cabinets.

III. Interfaces and Communication

1. **Control Interfaces*Siemens V20 Inverter 15KW of Model 6SL3210-5BE31-5UV0*

   - **Digital Inputs/Outputs**: 6 digital inputs (DI), 2 digital outputs (DO), supporting PNP/NPN signals.

   - **Analog Inputs/Outputs**: 1 analog input (AI, 0-10V or ±10V), 1 analog output (AO, 0-20mA or 0-10V).

   - **Communication Protocols**: Requires pairing with SINAMICS control units (e.g., CU240E-2) and supports communication protocols such as PROFINET, Modbus RTU, and USS.

2. **Expansion Capability*Chint converters (NVF2G-18.5/TS4 or NVF2G-18.5/PS4*

   - Safety function modules (e.g., STO) can be added via modular design to meet industrial safety standards (IEC 61508/SIL2).

   - Supports external braking resistors (optional based on application scenarios) for fast braking and energy feedback.

 IV. Certifications and Compliance

1. **International Certifications*Siemens 6EP1 252-0AA01 chain power supply*

   - Complies with CE certification and RoHS directives. Some channels mark it as "UL Open Typ" (not fully UL-certified, requiring users to assess North American compliance independently).

   - Meets electromagnetic compatibility standards such as IEC 61800-5-1 and EN 61000-6-2/6-4.

2. **Domestic Certifications**

   - No explicit mention of 3C certification, but complies with relevant Chinese low-voltage electrical standards.

V. Typical Applications and Functions

1. **Application Scenarios**

   - **Fans/Pumps**: Achieves energy savings by dynamically adjusting motor speed, reducing energy consumption by over 30%.

   - **Conveyor Belts and Lifting Equipment**: Supports soft starting and precise speed control to reduce mechanical impact.

   - **Household and Small Industrial Equipment**: Compatible with 220V single-phase power supply, suitable for home debugging or small production lines.

2. **Core Functions**

   - **Energy Feedback**: Feeds regenerative energy back to the grid through the braking chopper to improve system efficiency.

   - **Preventive Maintenance**: Built-in diagnostic functions monitor module temperature, current, and other parameters to provide early warnings of potential faults.

   - **Intelligent Protection**: Integrates overvoltage, undervoltage, and overheating protection, supporting remote monitoring and fault reset.

 VI. Procurement and Selection Recommendations

1. **Price Reference**

   - **North American Market**: Contact WhatsApp 86-13811255435 for inquiries, with additional shipping fees and tariffs applicable.

2. **Selection Considerations**

   - **Voltage Matching**: Ensure the input voltage matches the system design (200-240V) to avoid module damage due to voltage incompatibility.

   - **Power Requirements**: Select heavy or light overload modes based on the motor’s actual load to avoid long-term overload operation.

   - **Control Unit Compatibility**: Requires pairing with Siemens control units such as CU240E-2. It is recommended to use official tools (e.g., SINAMICS Startdrive) for parameter configuration.

 VII. Technical Support and Documentation

1. **Official Resources**

   - **User Manual**: Download the *SINAMICS G120 PM240-2 Power Module Operation Guide* from the Siemens official website, covering installation, parameter setting, and fault handling.

   - **Online Tools**: Use SINAMICS Startdrive software for quick commissioning, supporting automatic motor parameter identification and optimization.

Summary

The Siemens 6SL3210-1PB13-8AL0 is a cost-effective small and medium-power frequency converter module suitable for energy-saving control in 200-240V systems. Its modular design, wide temperature operating range, and rich interface functions make it widely applicable in industrial and civil scenarios. Domestic users can purchase conveniently through e-commerce platforms, while North American users need to focus on confirming certifications and supply channels. For higher power or North American-compliant products, consider the HV series or consult the manufacturer’s technical support.
